Next-Gen Image Clarity with the Digital Watchdog DWC-XSTD05MF 5MP Turret Camera

Jun 10, 2025 | Ip Video

DWC-XSTD05MF 5MP Turret Camera installed outside a commercial building

Cut the Core Drilling: SDC WPT Wireless Power Transfer Device Makes Retrofits Easy

Messing with door cores is one of the biggest headaches for security dealers retrofitting electrified hardware—especially when dealing with wood or fire-rated doors. Fortunately, the SDC WPT Wireless Power Transfer Device solves that problem by delivering power and data across the door gap without any moving parts, wires, or core drilling.

Ideal for both retrofit and new construction, this RF-powered solution simplifies installations, minimizes vandal-prone wiring, and keeps projects on schedule. Whether you’re updating an older access control system or installing electric locks on a wood or steel door, the SDC WPT gives you the power—literally—to get the job done cleanly and compliantly.

Key Product Features

  • Wireless RF power transfer—no door core drilling required
  • Compatible with steel and wood doors
  • Transfers both energy and data (REX, DPS, latch status)
  • Visual LED status indicator
  • Field-selectable dual voltage output (12VDC or 24VDC)
  • Up to 1/4” (7mm) door gap tolerance
  • Flexible mounting on latch, hinge, or top frame
  • No moving parts or exposed wires—zero wear points
  • Adjustable unlock trigger (1–90 seconds)
  • Includes fixed 4-second unlock trigger for standard REX

Use Cases & Dealer Benefits

The WPT is a retrofit-friendly, code-compliant solution designed for:

  • Failsecure Electrified Locks and Latches: Power mortise, cylindrical, or rim locks without wiring hassles.
  • High-Traffic Doors: Reduce wear and tear from wire loops and moving parts.
  • Historic and Finished Doors: Maintain door aesthetics without compromising functionality.
  • Healthcare and Schools: Perfect for touchless entry installations using wave-to-open sensors.
  • Compliance Upgrades: Ideal for projects needing to meet UL fire and burglary ratings.

Why Dealers Love It:

  • No Core Drilling = Faster Installs: Save labor and avoid damaging fire-rated or wood doors.
  • Reduced Callbacks: No wires to break or degrade over time.
  • More Tolerant Alignment: Easier to install than inductive wireless devices.
  • Upsell Opportunity: Bundle with electrified locksets, exit devices, and wave-to-open switches.
  • Profitable Retrofits: Unlock more margin on existing door openings where wiring is difficult.

Technical Summary

  • Power Input (Frame Side): 600 mA @ 24 VDC
  • Power Output (Door Side):
    • 600 mA @ 12 VDC
    • 300 mA @ 24 VDC
  • Door Gap Tolerance: Up to 1/4″ (7mm)
  • Alignment Tolerance: Horizontal & vertical < 5/64” (2mm)
  • Dry Inputs:
    • (1) 4-second fixed unlock trigger
    • (1) 1–90 second adjustable unlock timer
  • Dry Outputs (Frame Side):
    • (2) SPDT, 1A @ 30 VDC resistive
    • (2) SPST-NO, 100 mA @ 60 VDC resistive
  • Environmental Rating: -4°F to 140°F
  • Weight: 1 lb
  • Certifications:
    • UL 10C Positive Pressure Fire Tests
    • UL 1034 Burglary-Resistant Locking Mechanisms

Note: For use with failsecure (power-to-unlock) locks only. Not compatible with failsafe or continuously dogged locks.

How the SDC WPT Works

Unlike inductive systems that require precise coil alignment, the WPT uses RF energy, which:

  • Transmits power as radio waves across the door gap.
  • Converts the RF signal into usable DC voltage via an internal receiver.
  • Transfers data (REX, DPS, latch status) along with power.
  • Is less sensitive to vertical and horizontal misalignment than coil-based systems.

This makes the WPT more installer-friendly and reliable in real-world deployments—especially in field conditions where perfect alignment isn’t always possible.

Accessory Highlight: WPT Drill Jig

For installers working with solid or particle-filled wood doors, SDC offers a WPT Drill Jig Assembly (part #SDC-WPT), available from JustDoorToolz. This makes prep quick, clean, and precise—ensuring a secure, code-compliant fit for every install.

Partner with SESP for Your SDC Installations
Southeast Security Products represents SDC and other best-in-class manufacturers across the Southeast U.S., offering hands-on support, product expertise, and dealer-focused programs to help you grow your business. Whether you’re building your first smart home package, upgrading to next-gen connectivity, or integrating high-performance technology into a larger security system, we can help you select the right solutions to power your installations. Contact us today for pricing, training, or to request a demo of the WPT Wireless Power Transfer Device.

Visit sesproducts.com or reach out to learn more about how we can support your next project.

The DWC-XSTD05MF 5MP Turret Camera delivers crystal-clear resolution, advanced low-light performance, and NDAA compliance—making it an ideal upgrade for dealers looking to enhance IP surveillance systems in commercial or institutional settings. With built-in Star-Light Plus technology and true WDR, this compact IP camera captures detailed video even in difficult lighting conditions, helping security integrators reduce callbacks and deliver dependable results.

For dealers looking to upgrade camera systems with minimal friction and maximum reliability, this NDAA/TAA compliant camera is a strong performer in almost any lighting condition.

Key Product Features

  • 5MP Resolution at 30fps — Crisp video quality for forensic-level detail and better subject identification.

  • Star-Light Plus™ Technology — Enhanced low-light performance without sacrificing color accuracy or clarity.

  • True WDR (Wide Dynamic Range) — 120dB WDR ensures visibility in challenging lighting conditions, such as entrances or parking lots.

  • 2.8mm Fixed Lens — Wide field of view, ideal for general coverage.

  • Smart IR up to 100ft — Optimized infrared illumination that reduces overexposure and improves nighttime visibility.

  • IP67 Weatherproof and IK10 Vandal-Resistant Housing — Built to withstand the elements and physical tampering.

  • NDAA/TAA Compliant — Ready for government, education, and other regulated installations.

  • ONVIF Conformant, DW Spectrum® IPVMS and VMS Integration — Compatible with leading VMS platforms for flexible deployments.

  • Micro SD/SDHC/SDXC Card Slot (256GB max) — Supports edge recording for redundancy and bandwidth optimization.

  • 12VDC and PoE Support — Simplifies wiring and ensures reliable power.

Use Cases and Dealer Benefits

The DWC-XSTD05MF is purpose-built for integrators who demand performance and durability across a wide range of environments. Its fixed lens and wide-angle coverage make it ideal for both interior and exterior installations.

  • Retail Entrances and Store Interiors
    Capture detailed activity at entry points and monitor customer movement for loss prevention. Dealers can pitch this camera as a superior replacement for outdated dome or analog systems.

  • Building Exteriors and Perimeter Surveillance
    With Smart IR and IP67 protection, it delivers reliable nighttime performance, even in heavy rain or extreme temperatures.

  • Education and Campus Security
    A go-to solution for K-12 and higher education customers seeking NDAA-compliant technology. The wide field of view and reliable performance make it ideal for monitoring hallways, parking lots, and building entrances.

  • Logistics, Warehousing, and Distribution
    Warehouses benefit from edge recording during network drops and from low-light visibility in storage areas without supplemental lighting.

  • Municipal and Government Projects
    Its TAA compliance, compact design, and VMS compatibility make it a trusted choice for securing libraries, city buildings, and public access zones.

  • Quick Service Restaurants (QSR) and Drive-Thrus
    With Smart IR and a 2.8mm wide lens, this camera can capture vehicle and customer details at outdoor order windows, helping business owners resolve disputes and improve service.

  • Security System Refresh Projects
    Dealers can position this as a budget-friendly upgrade path for older 2MP or HD analog installs, helping clients future-proof their investment.

For security dealers, this camera provides a reliable upsell opportunity — giving end-users a significant upgrade in clarity and usability, especially in older systems where HD analog or 2MP IP cameras are still in use.

Plus, Digital Watchdog’s DW Spectrum® IPVMS compatibility ensures a seamless plug-and-play experience for both new installations and existing surveillance networks. The turret form factor also means faster aiming and simplified mounting for field technicians.

Optional Technical Summary

For integrators and engineers evaluating system compatibility and performance:

  • Image Sensor: 1/2.8” CMOS sensor for enhanced light capture and clarity.

  • Minimum Illumination: 0.06 lux in color, 0 lux with IR—ideal for dark environments.

  • True WDR: 120dB Wide Dynamic Range improves visibility when light varies greatly across the scene (e.g., bright doorways, storefront glass).

  • Compression Formats: Supports Smart Codec (H.264/H.265) for bandwidth-efficient streaming.

  • Max Bitrate: Up to 8Mbps.

  • MicroSD Card Slot: Accommodates up to 256GB for local recording.

  • Ingress/Vandal Ratings: IP67 waterproof and IK10 impact-resistant for durability.

  • Power Input: 12VDC or PoE (IEEE 802.3af Class 3), providing flexibility during installs.

  • ONVIF Profile S Conformant: Ensures interoperability with third-party VMS and NVRs.

Compared to legacy models or entry-level IP cameras, the DWC-XSTD05MF offers a step up in both performance and compliance. The compact turret design is installer-friendly, and Digital Watchdog’s DW Spectrum® IPVMS makes deployment even easier for techs and dealers already within the DW ecosystem.

Partner with SESP for Your DWC-XSTD05MF Installations

Southeast Security Products represents the DWC-XSTD05MF 5MP Turret Camera and other best-in-class manufacturers across the Southeast U.S., offering hands-on support, product expertise, and dealer-focused programs to help you grow your business. Whether you’re building your first smart home package, upgrading to next-gen connectivity, or integrating high-performance technology into a larger security system, we can help you select the right solutions to power your installations. Contact us today for pricing, training, or to request a demo of the DWC-XSTD05MF 5MP Turret Camera.

Visit sesproducts.com or reach out to learn more about how we can support your next project.
