Prima Smart Home Wireless Doorbell

Cut the Core Drilling: SDC WPT Wireless Power Transfer Device Makes Retrofits Easy

Messing with door cores is one of the biggest headaches for security dealers retrofitting electrified hardware—especially when dealing with wood or fire-rated doors. Fortunately, the SDC WPT Wireless Power Transfer Device solves that problem by delivering power and data across the door gap without any moving parts, wires, or core drilling.

Ideal for both retrofit and new construction, this RF-powered solution simplifies installations, minimizes vandal-prone wiring, and keeps projects on schedule. Whether you’re updating an older access control system or installing electric locks on a wood or steel door, the SDC WPT gives you the power—literally—to get the job done cleanly and compliantly.

Key Product Features

  • Wireless RF power transfer—no door core drilling required
  • Compatible with steel and wood doors
  • Transfers both energy and data (REX, DPS, latch status)
  • Visual LED status indicator
  • Field-selectable dual voltage output (12VDC or 24VDC)
  • Up to 1/4” (7mm) door gap tolerance
  • Flexible mounting on latch, hinge, or top frame
  • No moving parts or exposed wires—zero wear points
  • Adjustable unlock trigger (1–90 seconds)
  • Includes fixed 4-second unlock trigger for standard REX

Use Cases & Dealer Benefits

The WPT is a retrofit-friendly, code-compliant solution designed for:

  • Failsecure Electrified Locks and Latches: Power mortise, cylindrical, or rim locks without wiring hassles.
  • High-Traffic Doors: Reduce wear and tear from wire loops and moving parts.
  • Historic and Finished Doors: Maintain door aesthetics without compromising functionality.
  • Healthcare and Schools: Perfect for touchless entry installations using wave-to-open sensors.
  • Compliance Upgrades: Ideal for projects needing to meet UL fire and burglary ratings.

Why Dealers Love It:

  • No Core Drilling = Faster Installs: Save labor and avoid damaging fire-rated or wood doors.
  • Reduced Callbacks: No wires to break or degrade over time.
  • More Tolerant Alignment: Easier to install than inductive wireless devices.
  • Upsell Opportunity: Bundle with electrified locksets, exit devices, and wave-to-open switches.
  • Profitable Retrofits: Unlock more margin on existing door openings where wiring is difficult.

Technical Summary

  • Power Input (Frame Side): 600 mA @ 24 VDC
  • Power Output (Door Side):
    • 600 mA @ 12 VDC
    • 300 mA @ 24 VDC
  • Door Gap Tolerance: Up to 1/4″ (7mm)
  • Alignment Tolerance: Horizontal & vertical < 5/64” (2mm)
  • Dry Inputs:
    • (1) 4-second fixed unlock trigger
    • (1) 1–90 second adjustable unlock timer
  • Dry Outputs (Frame Side):
    • (2) SPDT, 1A @ 30 VDC resistive
    • (2) SPST-NO, 100 mA @ 60 VDC resistive
  • Environmental Rating: -4°F to 140°F
  • Weight: 1 lb
  • Certifications:
    • UL 10C Positive Pressure Fire Tests
    • UL 1034 Burglary-Resistant Locking Mechanisms

Note: For use with failsecure (power-to-unlock) locks only. Not compatible with failsafe or continuously dogged locks.

How the SDC WPT Works

Unlike inductive systems that require precise coil alignment, the WPT uses RF energy, which:

  • Transmits power as radio waves across the door gap.
  • Converts the RF signal into usable DC voltage via an internal receiver.
  • Transfers data (REX, DPS, latch status) along with power.
  • Is less sensitive to vertical and horizontal misalignment than coil-based systems.

This makes the WPT more installer-friendly and reliable in real-world deployments—especially in field conditions where perfect alignment isn’t always possible.

Accessory Highlight: WPT Drill Jig

For installers working with solid or particle-filled wood doors, SDC offers a WPT Drill Jig Assembly (part #SDC-WPT), available from JustDoorToolz. This makes prep quick, clean, and precise—ensuring a secure, code-compliant fit for every install.

Partner with SESP for Your SDC Installations
Southeast Security Products represents SDC and other best-in-class manufacturers across the Southeast U.S., offering hands-on support, product expertise, and dealer-focused programs to help you grow your business. Whether you’re building your first smart home package, upgrading to next-gen connectivity, or integrating high-performance technology into a larger security system, we can help you select the right solutions to power your installations. Contact us today for pricing, training, or to request a demo of the WPT Wireless Power Transfer Device.

Visit sesproducts.com or reach out to learn more about how we can support your next project.

Prima Smart Home Wireless Doorbell is the latest game-changer from Napco, built specifically for professional security dealers looking to add high-value video services without adding headaches. This wireless video doorbell is packed with AI-driven features and patented self-healing Wi-Fi, delivering an unbeatable combination of installation simplicity, reliable performance, and recurring revenue potential.

With the video doorbell market projected to hit $4 billion by 2030, dealers using the Prima Smart Home Wireless Doorbell are in the perfect position to claim their share—without dealing with the usual service call fallout.

Key Product Features

  • Patented Self-Healing Wi-Fi keeps video streaming even when customers change routers or passwords

  • Smart AI Human Detection minimizes false alerts from pets, wind, or moving shadows

  • HD video resolution up to 1536P, H.264 compression, and 10–15 FPS frame rate

  • 160° horizontal and vertical field of view for maximum coverage

  • IR night vision up to 10 feet for reliable low-light performance

  • Two-way audio with omnidirectional mic via app or Prima panel

  • Rechargeable 6400mAh battery with USB-C charging (5V/2A) or optional solar panel (PSOLAR)

  • Built-in LED strobe and siren for instant alert on alarms

  • Innovative mounting bracket allows the unit to keep functioning while being recharged

  • Optional plug-in chime accessory (#PCHIME)

  • Available in hardwired version (#PBELL) for use with 10–30VAC systems

Use Cases & Dealer Benefits

The Prima Smart Home Wireless Doorbell is tailor-made for dealers who want to streamline their installations and offer reliable smart home video functionality that’s deeply integrated with the Prima intrusion platform.

Where It’s Used

  • Residential front doors, porches, and entry gates

  • Multi-unit dwellings using the Prima Smart Panel

  • Light commercial storefronts or reception areas

Why Dealers Choose It

  • Ultra-fast setup: One-button pairing with Prima panel means no complex configuration or cloud account syncing.

  • No callbacks, no truck rolls: Patented Wi-Fi self-healing automatically reconnects after network changes, saving you hours of support time.

  • Reduce false alarms: AI-based human detection gives you smarter notifications, not constant noise.

  • App-based control + live video: View and communicate with visitors through the Prima app or smart panel in real time.

  • Drive recurring revenue: The doorbell’s built-in features and app integration create easy upsell paths to subscription services or monitoring plans.

  • Works with everything Prima: Seamlessly integrates with Napco’s growing smart home ecosystem, including cameras and sensors.

If you’re already installing the Prima platform, the wireless doorbell is a natural extension of your offering—and a solid moneymaker for years to come.

Technical Summary

Built for security-grade performance and ease of install, the Prima Smart Home Wireless Doorbell is a purpose-built device designed for the demands of professional integrators.

  • Model: PWBELL (wireless), PBELL (hardwired)

  • Camera: 2MP with HD video (up to 1536P), H.264 compression, 10–15FPS

  • Field of View: 160° (horizontal and vertical)

  • Wi-Fi: 802.11 a/b/g/n (2.4GHz only), plus 433MHz connection to panel

  • Audio: Live view with two-way communication and omni mic

  • Battery: 6400mAh rechargeable, USB-C 5V/2A

  • Weatherproofing: IP54 rated for outdoor use

  • Night Vision: IR range up to 10 ft.

  • Security: WPA-AES/P2 dual encryption

  • Mounting: Includes bracket, battery, USB-C cable, and hardware

  • Add-Ons: Optional plug-in chime (#PCHIME), optional solar panel (#PSOLAR)

And for dealers retrofitting homes with an existing wired doorbell, the hardwired version handles a broad 10–30VAC voltage range without rewiring.

Partner with SESP for Your Napco Installations

Southeast Security Products represents Napco and other best-in-class manufacturers across the Southeast U.S., offering hands-on support, product expertise, and dealer-focused programs to help you grow your business. Whether you’re building your first smart home package, upgrading to next-gen connectivity, or integrating high-performance technology into a larger security system, we can help you select the right solutions to power your installations. Contact us today for pricing, training, or to request a demo of the Prima Smart Home Wireless Doorbell.

Visit sesproducts.com or reach out to learn more about how we can support your next project.
